XCMG XLZ2103E road cold recycler soil stabilizer
• It adopts Weichai WP12N engine, which features advanced fuel system and inlet and exhaust system, National III emission standards, strong power and good performance.

• The hydraulic system adopts imported product of world-famous brand, which has the advantages like high allowed pressure, high efficiency, low noise, and complete functions; the pump is integrated with pressure limit valve, high-pressure safety valve, bypass valve and etc, which simplifies the hydraulic system for easy installation and service.

• The working devices can operate near the road shoulder, so that the machine can be widely used; the water spray device with self-suction function is of high measuring accuracy and convenient to operate; the rotor housing of optimized design has small resistance; the specially designed milling and mixing rotor has good quality and strong milling and mixing capability.

• It adopts the Meritor drive axle which has advanced design, reasonable structure, and reliable manufacturing quality.

• The cab is installed at the front which has a wide view; it is equipped with audio system, luxury seat, air conditioner, warm-air blower, and etc. providing a comfortable environment for higher work efficiency.

• The steering system has multiple steering modes like front axle steering, rear axle steering, and combined steering, which increases the effective work time.


Milling width
2300(2100)mm
Maximum milling depth
0-400mm
Tool spacing
18(15)mm
Number of tools
162
Milling wheel diameter (with tool)
1380(1350)mm
Cooling method
Water cooling
Model
WP12.460N
Number of cylinders
6
Rated power
338kw
Engine speed
1900rpm
Fuel consumption: full load
69.86kg/h
Working speed
0-2.7km/h
Walking speed
0-18.5km/h
Theoretical Gradeability (Work Block)
20%
Ground clearance
350
Weight / load
15000
Front axle load
6300(6000)kg
Rear axle load
21300(21000)kg
Shipping weight
21300(21000)kg
Fuel tank
650L
Hydraulic tank
380L
Water tank
1000L
Electrical system
24V
Machinery (length×width×height)
9232×3142×3450mm
