| Performance | Rated loading (kg) | 2500 |
| Overall weight (kg) | 5100 |
| Rated bucket capacity (CBM) | 0.8 |
| Maximum tractive force (kn） | 35 |
| Maximum breakout force (kn） | 25 |
| Maximum grade ability（°） | 25 |
| Maximum dump height（mm） | 2830 |
| Maximum dump height（mm） | 3848 |
| Maximum dump reach（mm） | 1124 |
| Overall dimension (L×W×H) （mm） | 5631*1870*2736 |
| Minimum turning radius（outside of wheels）（mm） | 5640 |
| Maximum steering angle | 31° |
| Oscillation angle | 5° |
| Engine | Model | YN38GBZ |
| Type | inline 、 water cooling 、dry cylinder、 injection |
| No. of cylinder-bore/stroke （mm） | 4-102×115 |
| Displacement （L） | 3.8 |
| Rated power（kW） | 76 |
| Idel speed (r/min) | 800-850 |
| Rated speed (r/min) | 2400 |
| Maximum torque N.m @speed r/min | 250-270 @ 1600-1800 |
| Min fuel-consume ratio | ≤225g/kw.h |
| Transmission system | Torque converter | 265 |
| Gearbox mode | Power shift normally engaged straight gear |
| Gear shift | Mechanical， 2forward shift 2 reverse shift |
| Maximum speed (km/h) | 21 |
| Drive axles | Main reducing mode | Bevel gear grade l reduction |
| Wheel base (mm) | 2568 |
| Wheel tread(mm) | 1470 |
| Ground clearance(mm) | 358 |
| Hydraulic system | System working pressure (Mpa) | 20 |
| Boom lifting time (s) | 7.2 |
| Total time (s) | 12.9 |
| Fuel tank capacity (L) | 94 |
| Brake system | Service brake | Air-assist hydraulic brake, disc brake |
| Parking brake | Manual disc brake |
| Tyre | Type specification | 16/70-20 |
| Front tyre pressure （kPa） | 350 |
| Rear tyre pressure （kPa） | 350 |
