XCMG Official 6 Ton Spider Crane ZQS125-5 China Brand New Telescopic Crawler Crane.

The biggest feature of XCMG ZQS125-5 is that it is crawler when getting off the car and can use outriggers when hoisting. Its chassis has the high flexibility of a crawler crane and the super stability of a car crane. It is very suitable for those narrow roads and slopes. Work sites with many roads and muddy ground.



optional functions and configuration: proportional remote control, dual power (diesel engine and electromotor), retracting boom with one button, tilt alarm function, automatic leg position detection, base block of leg, single part hook, bucket.


Model
ZQS125-5
Max. lifting momentkN.m100
Max. lifting capacitykg5500/1.8m
Max. outreachm16.7
Max. lifting heightm17.2
Travel widthmm1500
Rated Flow of Hydraulic SystemL/min80
Oil tank capacityL90
Rated pressure of Hydraulic SystemMpa18
Recommended Powerkw36.8
Hook speedm/min10(4/4)
Travel speedkmh0~3
Slewing Angle°360° full rotation
Crane weight(optional parts are not included)kg6000
Boom section type
Lower hexagon
Leg structure type
Baby hydraulic telescopic legs
Control type
Infinite + Limited Operation Control
